OGP
C-Vision
- Motorized 15 x 9” stage with manual fine adjustment, 2” focal travel
- 2D Measurement with Measure-X software, including Compare mode for conventional comparator use
- All LED Illumination with high-resolution surface images
- Field of View Accuracy:
- Low Mag: 0.0003”
- High Mag 4x (Standard): 0.00016”
- High Mag 10x (Optional): 0.00012”
- Stage Accuracy: (300 + 10L) µinch
OGP Flash 200
- 8x8x6″ (200x200x150mm) travel
- Renishaw SP25 Touch & Scanning Probe
- Flash TTL Laser
- 4th Axis Rotary
- Zone3 Metrology Software w/ 3D CAD Import
- Accuracy: XY – 2.0 +/- 6L/1000 µm, Z – 3.5 +/- 6L/1000 µm
SmartScope M7
- Motorized 10 x 6 x 8” Stage Travel
- Patented IntelliCentric-M Optics & Virtual Zoom with 20 MP camera
- Zone3 3D Metrology Software with CAD Import, ASME & ISO Compliant
- Multisensor capable using video as the primary sensor with touch probe, laser, and 4th/5th axis options
- XY Area Accuracy: 1.8 + 5L/1000 µm
- Z Linear Accuracy: 2.5 +5L/1000 µm
SprintMVP™
Formerly a RAM model, SprintMVP™ – Utilizes a 6.5:1 motorized, programmable zoom lens allows the user to focus at the optimum magnification. High speed, high accuracy stage on an all granite platform for thermal stability. Multi-sensor options include touch probe and dock, for hidden features, and DRS scanning lasers, for features requiring higher point densities.
StarLite 150
- Manual 6 x 3 x 5” stage travel
- 3D Measurement with Measure-X
- Software, 2D CAD Capability
- XY Area Accuracy: 4.5 + 8L/1000 µm
- Z Linear Accuracy: 7.0 + 8L/1000 µm
OGP FlexPoint 7.7.6
- 27x27x24″ Travel
- Renishaw SP25 Touch & Scanning Probe
- OGP SmartProbe Video Probe
- Renishaw PH10 with VersaFlex articulating head
- Zone3 Metrology Software w/ 3D CAD Import
- Accuracy: SP25 – 2.0-3.6 µm MPE, SmartProbe 3.0 µm MPE
- Includes install, calibration, & training
SNAP™
Formerly a RAM model, SNAP™ Large FOV Video Measurement Systems are compact measuring systems that integrate perfectly from the shop floor, to the lab, or as part of an automated work cell. Rugged construction and an open work envelope make SNAP easy to implement in virtually any manufacturing setting. SnapShot identifies and measures features instantly – without programming – and Auto-ID allows for automatic identification and inspection of programmed parts without the need for fixturing.
Benchmark
Formerly a VIEW model, Benchmark is a compact floor model system engineered for high performance and reliability. Its stage is ideal for medium format metrology applications that require high throughput, accuracy, and precision making it a world-class metrology system.
Pinnacle
Formerly a VIEW model, Pinnacle delivers unmatched accuracy and throughput, with the lowest cost of ownership for any automated measuring system of its kind. State-of-the-art linear motor control technology provides the fastest, most reliable platform available for high volume operation in production environments ranging from cleanrooms to factory floors.
