HURCO VM15D Milling Center
The Hurco VM15Di is a compact yet powerful 3-axis CNC machining center that packs a spacious work envelope, fast rapids, and an efficient direct-drive spindle into a small footprint. Designed for job shops and precision manufacturers, it offers excellent versatility, high productivity, and smooth operation in a reliable package.
| Specification | HURCO VM15Di |
|---|---|
| Table Size | 35.4″ x 16″ |
| X Travel | 30″ (762 mm) |
| Y Travel | 16″ (406 mm) |
| Z Travel | 20″ (508 mm) |
| Spindle Taper | CAT/BT 40 (BIG‑PLUS) |
| Maximum Spindle Speed | 12,000 RPM |
| Spindle Power | ~22.8 HP (17 kW) |
| Table Load Capacity | 1,500 lbs (680 kg) |
| Automatic Tool Changer | 24 Stations |
| Rapid Feedrates | ~1,417 IPM (X/Y), ~1,181 IPM (Z) |
| Machine Weight | ~7,000 lbs (3,360 kg) |
